This video details a complete installation and review of the Renogy 3.8kWh "GO FAR RV Solutions Kit" into a 2021 inTech Flyer Discover camper / toy hauler. This kit has the absolute beginner in mind because it lays everything out for you with very clear instructions and "paint by numbers" assembly.

In the past, RV Solar Kits have bundled components together without the necessary wiring, fuses, switches, and busbars. With the new line of RV Solution Kits, both 3.8kWh and 7.6kWh, Renogy puts nearly everything you need to install your off-grid kit in a weekend into one fantastic package.

Karin previously had zero experience with off-grid RV solar power or electrical installations in general. By the end of our time together, she not only learned how to install everything in the kit, she could explain it all to her partner. She's off-the-grid and going!

Check out the Go Far RV Solutions Kit to see what's included: https://renogy.sjv.io/dyeyyK

US Customers SAVE $$ with "GOFAR" promo code!
1. $200 off a Go Far RV Solution Kit - https://renogy.sjv.io/dyeyyK
2. $300 off Go Further RV Solution Kit - https://renogy.sjv.io/WOAXoA

Canada Customers SAVE 6% with "CANLIFE" promo code!
1. Go Far RV Solution Kit - https://renogy.sjv.io/aN65eM
2. Go Further RV Solution Kit - https://renogy.sjv.io/aN6WEY

What isn't included in the kit?
Because the length between the Starting Battery and the DC to DC Battery Charger will be different on every RV installation, the cable and accessories needed to connect these isn't included with the other wiring and accessories in the kit.

Required Additional Gear for Towable RV (for DC to DC Charger Installation):
1. 6AWG (16.0 mm²) Red and Black Cable
2. 6AWG (16.0 mm²) Terminal Lugs
3. 50A Anderson Connectors - https://tinyurl.com/2s456amw

Optional Additional Gear We'd Recommend:
1. Waterproof Cable Housing - https://renogy.sjv.io/zzPmx0
2. Battery Disconnect Switch (engine) - https://tinyurl.com/bs79ek84
3. Battery Selector Switch (solar) - https://tinyurl.com/mw5nrz2z
4. Anderson Connector Holder - https://tinyurl.com/3z7zphpy
5. 12AWG Grounding Wire for Inverter
6. Renogy 400W Lightweight Portable Panel (See Note*) - https://renogy.sjv.io/xkdn7O
7. Renogy MC-4 Solar Panel Extension Cord x 2 - https://renogy.sjv.io/DW13Mo
8. Renogy MC-4 - SAE adapter - https://renogy.sjv.io/k492K0
9. Renogy One CORE Monitor - https://renogy.sjv.io/DKbgDG
10. Conduit for 6AWG Engine Source Cable

*The factory installed SAE solar port on this inTech trailer was meant to be used with a specific solar panel, the port has a reversed polarity SAE plug (positive and negative are reversed). This means to use any other company's solar panel, including Renogy's, you will need a reverse polarity SAE adapter, these are inexpensive and can be found on many online retailers like Amazon, https://tinyurl.com/4232u4dr

To test if your plug has reversed polarity, insert the positive probe on your voltage meter, in the positive plug end, and the black probe into the negative. If you see a negative voltage reading, then your polarity of the plug is reversed.


Timestamps:
0:33 Installation Overview
1:09 Kit Components
2:12 Thoughts on the Kit
3:34 Installation Location Intech Flyer Discover
4:22 200W ShadowFlux Solar Panel Installation
7:41 50A DC to DC with MPPT Installation
12:41 300Ah LiFePO4 Battery Installation
13:56 2000W Inverter Installation
16:04 Turning On & Testing
16:42 Connecting to DC Home App
17:41 Engine Charging Testing
18:07 Solar Charging Testing (200W)
18:29 Solar Charging Testing (400W Portable Panel)
19:23 Inverter Testing
20:49 Shore Power Converter Lithium Setting
21:16 Conclusion and Assessment

This kit is a huge improvement on previous kits and will really help first time DIYers install with confidence. Good luck, ask questions, and let us know how it works out for you!


~~~~~~~~~~
Disclaimer: Most of the videos we make include affiliate links and paid sponsorship, this helps keeps our information free and us on the road (12 years and counting!).

This video is intended to help users plan, organize, calculate, and install a personal DIY solar powered electrical system. We, Shari & Hutch (Freedom in a Can, LLC), are neither professional electricians nor solar installers; we are educators who have learned to install our own system and to empower others to do the same. If you have questions, reach out in the comments section and we'll get back to you.

If you need further assistance beyond our advice, consult a solar professional or certified electrician. Electricity is dangerous, so do your homework, take it one step at a time, and good luck!
